SA M5 050 19 080
Termékszám:
SAM505019080
11
Suitable for Zeiss: 600331-8093-000
Suitable for Zeiss: 600331-8093-000
SA M5 050 19 080
Termékszám:
SAM505019080
Star Styli ; base: aluminium; stem: carbide; ball: ruby
The star styli in this product group are styli with five fixed arms. The solid design allows them to be used on high force measuring instruments.
| Thread size: | M5 |
|---|---|
| DK: | 5.0 |
| L: | 98.0 |
| customFields.itp_product_attributes_l_1: | 59.5 |
| DG: | 19.0 |
| DG (1): | 16.0 |
| ML: | 32.0 |
| DS: | 3.5 |
| DS (1): | 3.5 |
| A: | 80.0 |
| B: | 28.0 |
| Stem Material: | carbide |
| Base Material: | aluminium |
| Probe ball material: | ruby |
| Súly: | 62.5 |
| Compatible with: | Renishaw, Zeiss |
| Zeiss No.: | 600331-8093-000 |
| Renishaw-No.: | A-5555-0215 |
